DIPERK 16KW DIESEL GENERATOR (1 PHASE)

Model Name: DP16D6-1

Product Type: Generator Packages

Description

Engineered specifically for Canadian marketplace, the DiPerk DP16D6-1 features the Perkins 403D-15G engine which continues to set new standards in the compact engine market. This 1.5 litre, naturally aspirated 3 cylinder vertical in-line engine offers impressive performance , superb fuel economy, excellent noise attenuation, lightweight power, low emissions and low operating costs.The Leroy Somers brushless alternator utilized on this model is manufactured to exact specifications using the best manufacturing methods. DiPerk generators use electronic technology to control the voltage with a voltage variation of less than 0.25% throughout the entire power range.


Specifications

Power Ratings: 16kW Standby / 14kW Prime

Engine: Perkins 403D, Turbocharged, heavy duty diesel engine, 4 stroke, 1800rpm, Liquid cooled, Electronic governed

Alternator: Leroy Somers, 12 Lead brushless alternator. IP23 drip-proof protection, Insulation class H. Electronic Automatic voltage regulation, UL1446 LISTED (1 Ph 120/240V)

Controls: Deep Sea DSE4520, ADVANCED Digital auto-start/stop control panel. All genset parameter, alarms and control functions.

Battery Charger: DSE9470 10A 12V MKII is an intelligent switch-mode battery charger that can be programmed for different charging curves which helps maximize battery life. The charger continues to operate during cranking and running and accepts multiple AC voltage connections.

Battery: Varta 60Ah 580 CCA maintenance free battery

Jacket Water Heater: Hotstart TPS202GT10-008 2kw coolant heater designed to maintain optimal coolant temperature to make sure your generators start on time – every time.

Fuel Tank: Integral 145L (38 Gal) diesel fuel tank complete with fuel level sender

Emissions Compliancy: Canada Stationary

Engine Warranty: Standby: 3 Years - 1500 hours (500 hours per year)

Prime: 1 Year - Unlimited Hours

Generator Package Warranty: 1 Year - 1000 hours

Quality: Designed and built to ISO9001 & CSA Standards.
